FFU Fan Filter Unit

Fan Filter Units

A self-powered terminal purification device combining a fan and HEPA/ULPA filter, with modular design and air outlet speed of 0.45m/s±20%.

Suitable for cleanrooms, clean booths, clean production lines, assembled cleanrooms, and local clean areas of various process equipment in any cleanliness class.

Inquire Now Next Product

Product Features (Six Core Advantages

Multiple speed control methods supported

Extremely low power consumption, effectively reducing costs

Easily compatible with various HEPA and ULPA filters

Multi-wing centrifugal fan provides high air volume and static pressure for different environments

Each unit is scanned and tested with a dust particle counter according to ISO14644-1 before delivery to ensure quality

Eight Core Advantages

AC FFU power consumption is only 120W, 60% of similar products, saving electricity bills

Small current allows using smaller wires, saving wiring costs

American fan, body temperature 20% lower than similar products, saving cleanroom cooling capacity

Taiwanese motor + pyramid structure, small force and strong stability

SKF bearings, 60,000 hours of failure-free operation, reducing after-sales worries

Certified by ISO9001, CE, UL, ensuring quality

New technology upgrades extend FFU life by 2 years

Reliable quality, saving maintenance time and labor costs

Standard Specification Parameters (Customizable)

Specification Model	FFU-2×2	FFU-2×4	FFU-4×4
Overall Dimensions (LWH)	575×575×250mm	575×1175×230mm	1175×1175×230mm
High - Efficiency Filter Dimensions	570×570×69mm	570×1170×69mm	1170×1170×69mm
Air Volume (m鲁/h)	500 - 700 (Speed - Adjustable)	800 - 1300 (Speed - Adjustable)	1800 - 2300 (Speed - Adjustable)
Power (W)	80 - 120 (Speed - Adjustable)	120 - 170 (Speed - Adjustable)	130 - 180 (Speed - Adjustable)
Weight (KG)	15	25	45
Noise	≤52dB	≤55dB	≤58dB
Motor Type	AC Centrifugal Motor
Wind Speed (m/s)	0.3 - 0.6
Cleanliness	Class 100 (US Federal Standard 209E)
Power Supply	220V/50Hz. Contact us if there are other special power supply requirements.
Housing Material	Aluminum - Zinc - Coated Sheet, Painted Cold - Rolled Sheet, Stainless Steel Sheet

After-sales Service

Establish user files and regularly track product quality and usage

Free technical consultation and training to solve usage problems

1-year warranty for normal use, free maintenance and replacement of damaged parts (excluding vulnerable parts);For abnormal use or out of warranty, maintenance fees and component costs will be charged as appropriate.
